Threaded quick connectors help the bathroom industry valve inspection to improve efficiency-

Threaded quick connectors are mainly used for water testing and sealing testing in the bathroom industry, which can quickly seal and connect the product to be tested and the water pipe. Replace the previous way of workers manually screwing the hexagonal nut of the braided pipe, which is convenient and fast, with good sealing and more stable product testing.

[ Details ]

New energy all-in-one quick connection solution-

In the testing field of new energy vehicles, the testing of battery packs is a very important part of the vehicle assembly, testing and quality control process. Whether it is waterproof and dustproof air tightness testing, or package body testingEOLIsoelectric performance related tests are all indispensable parts to ensure the normal operation of new energy vehicles. In previous tests, each test was independent. In each test process, an independent set of test tooling is required. Such as airtightness test......

[ Details ]

Optimization Scheme for Rapid Test Connector of Three Electric Systems of New Energy Vehicles-

The three-power system of new energy electric vehicles includes motors, electronic controls, and batteries. The three-power system is a key component that distinguishes new energy vehicles from traditional vehicles. For example, motors and electronic control systems, as a replacement for traditional engine (transmission) functions, directly affect the performance of the vehicle. Stability and safety are particularly important.

[ Details ]

CZ105 filling connector operation manual-

CZ105 is used to connect G5/8 externally threaded cylinder valves for fast filling of compressed gas. There are various versions according to actual cylinder valve requirements. The operating pressure is up to 240bar. It can meet ordinary compressed gases, such as nitrogen, oxygen, air, etc. There are other series of CZ filling connectors to meet a variety of cylinder valve interface needs.

[ Details ]

Application of CZ Series Cylinder Filling Connector-

The CZ series gas cylinder special connector can easily solve the traditional filling pain points. The CZ series is used for the filling of compressed gas. The product connection is simple. Pick up the lifting ring and connect it to the gas cylinder nozzle, and put down the lifting ring to connect the inflation. The whole process takes about 5 seconds, which greatly improves the connection efficiency. When inflating, the anti-drop pin will pop up the locked connection to prevent accidental collision from causing the connector to disconnect, ensuring the reliability and convenience of inflation.

[ Details ]

Low pressure internal expansion anti-scratch joint-

The G25A-PA series connectors benefit from the addition of the chamfer of the large countersink at the front end, which ensures non-destructive contact during the entire insertion process and the existence of the limit gasket, so that the sealing ring can be in the most suitable sealing position, improving the stability of the seal.

[ Details ]

New energy wiring harness connector airtight test quick tooling-

Wire harness airtightness test is a necessary test process in the production process of new energy vehicles, including routine cable test, electrical connector test, terminal test, etc. It is necessary to use the corresponding quick connector to seal one end of the wiring harness, inflate or block, and connect the leak detector and other related equipment to check the waterproofing qualification of the product seal.

[ Details ]

Non-destructive quick sealing joints for various solenoid water valves-

The new product external thread non-destructive solution G60P series solves the above user test connection problems. Ensure the high efficiency of the connection without affecting the appearance of the product. The straight-through method of the tail can ventilate or pass liquid, the flow is not discounted, and the efficiency is doubled. If you have similar questions, please feel free to contact "GripSeal" for quick sealing.

[ Details ]

Automatic detection and liquid addition of air conditioner external unit-

The moving tray comes to the designated location with the assembly line. After automatically scanning the code, the movable docking plate of the fixed station is docked with the plate of the tray from top to bottom.C20After the series male and female heads are connected, vacuum and automatic liquid addition will start. The separated plate will start from the lock to ensure good sealing performance, so that the product can enter the next link with the moving tray.

[ Details ]

Use scheme of pneumatic automatic quick connector for threaded pipe-

Threaded pipe automatic quick connectorIt is often used in kitchen and bathroom appliances, instrumentation, fuel engines, new energy and other industries to quickly seal and connect products to assist in completing more product tests, such as airtight testing, waterproof and dustproof testing, etc.

[ Details ]
