New Energy Vehicle Testing
New Energy Vehicle Quick Connector Solution
Project introduction

GripSeal New energy vehicle quick connectors provide quick connection solutions for new energy vehicle battery packs, electric control boxes, motors, and corresponding brakes, heat dissipation, axles, steering gear, pipelines, and pump valves, doubling the testing efficiency.

New energy vehicle quick connector solution

project requirement

The production process of new energy vehicles requires a large number of tests on each major component or the whole vehicle, including air tightness testing, performance testing, aging testing, etc. These test benches are usually very expensive, and the test tempo is also very tight. However, the testing process requires plugging and connecting various internal and external threads, water outlets, etc., which consumes a lot of connection time, is labor-intensive, and has a high probability of leakage. These leaks are not easy to detect and lead to more misjudgments, especially when there are many nozzles. It seriously affects the production rhythm, and the investigation is very difficult. Even due to misjudgment, high-priced products are scrapped in batches, with large potential losses.

New energy vehicle quick connector  New energy vehicle quick connector

Need a connector solution that can quickly connect and ensure the sealing effect of the connection?

plan description

GripSeal quick connector, one-second connection, instant sealing

  • Inlet and outlet connector

    You can choose.G70The flange pipe connector can meet both water and airtight leak detection. If it is only airtight leak detection, you can chooseG35Tube hole connector, light and durable. Can be selected for low voltage occasionsG25Pipe hole connector, there are many types in stock, economical. Automation can be selectedG10orG10ProPneumatic outer tube connector to meet the requirements of automated connection.

  • J2044Standard water inlet and outlet

    You can choose.G70JSpecial-shaped pipe connector, which can meet the requirements of water supply or airtight leak detection, fast connection, reliable sealing and convenient maintenance. According to the situation, you can also choose the shut-off valve versionG70J-V。

  • Internal and external thread connector

    You can choose.G80orG80SShort internal thread connectors, available in various lengthened neck versions, can be provided, whether it isM10stillM12Or other internal thread specifications,G80The threaded connection can be completed in less than a second, providing a high sealing level and easy operation.

  • Thin plate hole connector

    You can choose.G80LTThe thin plate hole connector can quickly connect the thin plate hole parts.

  • Electrical connector seal

    You can choose.G25ECustomized electrical connectors can be used in pneumatic or manual solutions to meet automatic or manual connection requirements.

Program advantage
one second connection

one second connection

GripSeal connectors are all based on1The second connection is the design point, which improves the connection efficiency at least compared with the traditional clock in hoop or winding thread scheme10Times more.

instantaneous seal

instantaneous seal

The key to GripSeal connectors is an optimized sealing design that reduces the wear of the sealing ring and achieves a reliable seal while connecting. It can be sealed well when connected, especially in the case of leak detection or multi-pipeline sealing, our sealing reliability can be reduced90%The above connection leakage problem caused the test error.

customization capability

customization capability

No matter whether it is a standard nozzle or a special nozzle, GripSeal customizes reliable quick connectors based on a variety of sealing technologies to provide customers with turnkey sealed connection solutions.

reference customer

reference customer

From well-known new energy vehicles in the market, to start-up new energy vehicles, to auto parts manufacturers, tens of thousands of GripSeal connectors are helping customers save testing time and reduce test errors in the market.

Worry-free service

Worry-free service

GripSeal worry-free service greatly reduces the risk of customer selection, and effectively protects customers' investment, striving to reduce the cost of use throughout their lifespan.

GripSeal connector

Use GripSeal connector
Let customers test efficiencylift10double
connection leakage risklower90%
false positive ratio of test systemlower90%

Choosing GripSeal comprehensive connectivity solution not only allows for new energy vehicles, but also extends to the traditional automotive industry
Help improve test efficiency, reduce personnel labor intensity, and reduce the risk of misjudgment
